Skystars Fly Stack – F722 Mini HD Pro FC + KM35 PRO 35A BLHeli_32 3-6S 4-in-1 ESC – 20×20

The SkyStars Fly Stack features an F722 Mini HD Pro Flight Controller and a Kramam PRO 35A BLHeli_32 4-i-n1 ESC with a 20×20 mounting pattern!

Features

Designed the LED installation position in the four corners, supporting WS2812 Programable LED.
Supports serial receivers (CRSF, SBUS, iBus, Spektrum). Support 3.3V Satellite Receiver.
High-performance / low-noise / high-sensitivity IMU. BMI270 with 6-axis gyro and accelerometer.
Support connect DJI HD air module.
Input voltage10V-26V (3-6S)
Automatic voltage monitoring.

Specifications

F722 Mini HD Pro FC

MCU: STM32F722RGT6 216MHz
IMU: BMI270 (SPI)
OSD: Betaflight OSD & DJI HD OSD (UART6)
6 hardware UARTS (UART1,2,3,4,5,6)
Barometer: YES
Buzzer Pad: YES
5V 2A & 10V 2A
Input Voltage: 3-6S Lipo
Blackbox: 16MB
Firmware: SKYSTARS F7HDPRO
Dimensions: 31x30x7.8mm
Mounting Holes: Standard 20mm/M3 or M2 square to the center of holes
Weight: 6g

KM35 PRO 35A BLHeli_32 4-in-1 ESC

Input voltage: 3-6S LiPo
Con.Current: 35A
Peak Current: 45A≥ 10S
Firmware: BLHeli_32
Support: Dshot 600/1200
Mounting hole : 20X20 mm/M3
BEC: No
Product size: 31*36*3.9mm
Weight: 7.8g

Package COntents

1x Skystars ESC
1x Skystars Flight Controller 20×20mm

Width	6.00 (cm)
Height	6.00 (cm)
Depth	3.00 (cm)
Mounting	20×20
CPU	F7
Amps	35
